W Shaped MoSi2 Heating Element 220V 380V Moly Disilicide For Vacuum Furnace

MOQ : 10pcs

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : Spark Industry (Henan) Co., Ltd.

Delivery Time : 15 work days

Packaging Details : WOODEN CASE

Thermal Conductivity : 52 W/m·K

Heating Zone Length : Up to 1000 mm

Operating Voltage : Up to 240 V

Shape : W type

Maximum Power : Up to 2000 W

Size : Customizable

Density : 6.5 g/cm3

Electrical Resistivity : 1.2 μΩ·m

Max Temperature : 1800°C

Cold Zone Length : Up to 200 mm

Application : High temperature industrial heating

Surface Load : Up to 4 W/cm2

Material : Mosi2

Hot Zone Length : Up to 500 mm

Place of Origin : China

Brand Name : SONGYU

Contact Now

W type Mosi2 Heating Element

The W-shaped MoSi2 heating element is a remarkable innovation in the field of heating technology. Crafted with precision and made from high-quality molybdenum disilicide, it offers exceptional heat resistance and durability. Its unique W-shape design not only enhances the aesthetic appeal but also maximizes heat transfer efficiency. This heating element is capable of withstanding extremely high temperatures, making it ideal for a wide range of industrial applications such as furnaces, kilns, and heat treatment processes. With its reliable performance and long service life, it is a cost-effective solution for businesses looking for efficient heating options.

Voltage 220V/380V
Heating Zone Single/Double
Thermal Shock Resistance Good
Diameter 3/6/9/12mm
Material Mosi2 (Molybdenum Disilicide)
Length 100/200/300/400/500/600/700/800/900/1000mm
Features High temperature resistance, fast heating, long service life
Application High temperature furnace, vacuum furnace, sintering furnace, heat treatment furnace, etc.
